ULTRA/DCG Dual Cure Emulsion for Solvent Ink

ULTRA/DCG Dual Cure Emulsion for Solvent Ink



ADD TO CART: $22.50



Product Code: E-0113


Size for Ultra*:


Qty:
Overview


ULTRA/DCG Dual Cure Emulsion for Solvent Ink


Preparation of Screen and Emulsion:

Apply two coats on of ULTRA/DCG Dual Cure Emulsion the squeegee side and two coats on the print side of the screen. Let the screen completely dry before exposure, by placing the frame print side downwards. Expose the screen from the print side and wash it from the same side. Again dry the screen completely in a room with a low relative humidity. If the relative humidity is over 65%, more exposure time is required, approximately 1.4 times. After washing the screen, make sure that the screen is fully cured. One way to find is to rub the finger on the squeegee side and feel the sliminess. If any residual emulsion gets on to the finger, it shows the uncured emulsion- the exposure in that case should be increased. If some fine lines do not open, or open with difficulty, it indicates over-exposure.

Exposure: The longer distance from the exposure light to the screen, the colored mesh, higher humidity and thicker coating of emulsion increase the exposure time. With one coat on each side, a distance of approximately 8" on a white 156 mesh, expose based on the following directions:

Specification Data:
  • COLOR: GREEN
  • VISCOSITY: 14,000+16,000cps@ 20rpm at 75 F
  • PH 5.5
  • 3 Fluorescent Tubes each with 40 watts 320 Seconds
  • Metal Halide- 5000 watts 120 Seconds
**Avoid heat & freezing**
